HP 1910 - MAC Address Configuration Example

188
Figure 176 Setting the aging time for MAC address entries
3. Configure the aging time for MAC address entries as described in Table 53.
4. Click Apply.
Table 53 Configuration items
Item Descri
p
tion
No-aging Specify that the MAC address entry never ages out.
Aging time Set the aging time for the MAC address entry
MAC address configuration example
Network requirements
Use the Web-based NMS to configure the MAC address table of the device. Add a static MAC address
00e0-fc35-dc71 under GigabitEthernet 1/0/1 in VLAN 1.
Creating a static MAC address entry
1. Select Network > MAC from the navigation tree.
By default, the MAC tab is displayed.
2. Click Add.
The page shown in Figure 177 appears.
3. Configure a MAC address entry:
a. Enter MAC address 00e0-fc35-dc71.
b. Select static from the Type list.
c. Select 1 from the VLAN list.
d. Select GigabitEthernet1/0/1 from the Port list.
4. Click Apply.
