504
Recommended priority trust mode configuration procedure
Ste
Remarks
1. Configuring priority trust mode on a port
Required.
Set the priority trust mode of a port.
Adding a class
1. Select QoS > Classifier from the navigation tree.
2. Click the Create tab to enter the page for adding a class.
Figure 482 Adding a class
3. Add a class as described in Table 145.
4. Click Create.
Table 145 Configuration items
Item Descri
tion
Classifier Name
Specify a name for the classifier to be added.
Operator
Specify the logical relationship between rules of the classifier.
• and—Specifies the relationship between the rules in a class as logic AND. The
device considers a packet belongs to a class only when the packet matches all the
rules in the class.
• or—Specifies the relationship between the rules in a class as logic OR. The device
considers a packet belongs to a class as long as the packet matches one of the rules
in the class.
