HP 1910 User Manual

503
Table 144 Recommended QoS policy configuration procedure
Ste
p
Remarks
1. Adding a class
Required.
Add a class and specify the logical relationship
between the match criteria in the class.
2. Configuring classification rules
Required.
Configure match criteria for the class.
3. Adding a traffic behavior
Required.
Add a traffi
c behavior.
4. Configure actions for the behavior:
{ Configuring traffic redirecting for a traffic behavior
{ Configuring other actions for a traffic behavior
Required.
Use either method.
Configure various actions for the traffic behavior.
5. Adding a policy
Required.
Add a policy.
6. Configuring classifier-behavior associations for the
policy
Required.
Associate the traffic behavior with the class in the
QoS policy.
A class can be associated with only one traffic
behavior in a QoS policy. Associating a class
already associated with a traffic behavior will
overwrite the old association.
7. Applying a policy to a port
Required.
Apply the QoS policy to a port.
Recommended queue scheduling configuration procedure
Ste
p
Remarks
1. Configuring queue scheduling on a port
Optional.
Configure the queue scheduling mode for a port.
Recommended rate limit configuration procedure
Ste
p
Remarks
1. Configuring rate limit on a port
Required.
Limit the rate of incoming packets or outgoing packets
of a physical port.
Recommended priority mapping table configuration procedure
Ste
p
Remarks
1. Configuring priority mapping tables
Optional.
Set priority mapping tables.
