HP 1910 User Manual

505
Configuring classification rules
1. Select QoS > Classifier from the navigation tree.
2. Click Setup to enter the page for setting a class.
Figure 483 Configuring classification rules
3. Configure classification rules for a class as described in Table 146.
4. Click Apply.
Table 146 Configuration items
Item Descri
p
tion
Please select a classifier Select an existing classifier from the list.
Any
Define a rule to match all packets.
Select the box to match all packets.

HP 1910 Specifications

General

Model	HP 1910
Category	Switch
Port Type	10/100/1000BASE-T
Layer	Layer 2
PoE Support	No
MAC Address Table Size	8K entries
VLAN Support	Yes
Management	Web-based GUI
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Jumbo Frame Support	Yes
Ports	24
