163
Figure 151 Creating a VLAN interface
3. Configure the VLAN interface as described in Table 43.
4. Click Apply.
Table 43 Configuration items
Item Descri
tion
Input a VLAN ID:
Enter the ID of the VLAN interface to be created. Before creating a VLAN interface,
make sure that the corresponding VLAN exists.
Configure
Primary
IPv4
Address
DHCP
Configure the way in which the VLAN interface gets an IPv4 address.
Allow the VLAN interface to obtain an IP address automatically by
selecting the DHCP or BOOTP option, or manually assign the VLAN
interface an IP address by selecting the Manual option.
These items
are available
after you
select the
Configure
Primary IPv4
Address box.
BOOTP
Manual
IPv4
Address
Configure an IPv4 address for the VLAN interface.
This field is available after you select the Manual option.
Mask
Length
Set the subnet mask length (or enter a mask in dotted decimal
notation format).
This field is available after you select the Manual option.
