242
Figure 207 The Global Setup tab
3. Set the global LLDP setup as described in Table 77.
4. Click Apply.
A progress dialog box appears.
5. Click Close on the progress dialog box when the progress dialog box prompts that the
configuration succeeds.
Table 77 Configuration items
Item Descri
LLDP Enable Select from the list to enable or disable global LLDP.
CDP Compatibility
Select from the list to enable or disable CDP compatibility of LLDP.
IMPORTANT:
• To enable LLDP to be compatible with CDP on a port, you must set the CDP
operating mode on the port to TxRx in addition to enabling CDP compatibility
on the Global Setup tab.
• Because the maximum TTL allowed by CDP is 255 seconds, you must make sure
that the product of the TTL multiplier and the LLDPDU transmit interval is less than
255 seconds for CDP-compatible LLDP to work correctly with Cisco IP phones.
