244
By default, the Local Information tab is displayed, as shown in Figure 208. Table 78 describes the
fields.
Figure 208 The Local Information tab
Table 78 Field description
Field Descri
Port ID subtype
Port ID representation:
• Interface alias.
• Port component.
• MAC address.
• Network address.
• Interface name.
• Agent circuit ID.
• Locally assigned—Locally-defined port ID type other than those listed
above.
Power port class
The power over Ethernet port class:
• PSE—Power supply device.
• PD—Powered device.
Port power
classification
Port power classification of the PD:
• Unknown
• Class0.
• Class1.
• Class2.
• Class3.
• Class4.
Power type
The PoE type is Type 2 PSE, which supplies power from 0 to 30 W, a voltage
from 50 to 57 V, and a maximum current of 600 mA.
Power source
Power supply type for a PSE:
• Unknown—Unknown power supply.
• Primary—Primary power supply.
• Backup—Backup power supply.
