HP 1910 User Manual

294
Figure 258 Configuring MLD snooping port functions
3. Configure the parameters as described in Table 88.
4. Click Apply.
Table 88 Configuration items
Item Descri
p
tion
Port
Select the port on which advanced MLD snooping features will be configured. The port
can be an Ethernet port or Layer 2 aggregate interface.
After a port is selected, advanced features configured on this port are displayed at the
lower part of this page.
TIP:
Advanced MLD snooping features configured on a Layer 2 aggregate interface do not
interfere with features configured on its member ports, nor do they take part in aggregation
calculations. Features configured on a member port of the aggregate group does not take
effect until the port leaves the aggregate group
VLAN ID
Specify a VLAN in which port functions are to be configured.
The configurations made in a VLAN take effect on the ports only in this VLAN.
Multicast Group
Limit
Configure the maximum number of IPv6 multicast groups on a port.
With this feature, you can regulate IPv6 multicast traffic on the port.
IMPORTANT:
When the number of IPv6 multicast groups on a port exceeds the limit that you are setting, the
system deletes all the IPv6 forwarding entries related to that port from the MLD snooping
forwarding table. The receiver hosts on that port can join the IPv6 multicast groups again
before the number of IPv6 multicast groups on this port reaches the limit.
