HP 1910 User Manual

489
Figure 469 Configuring a rule for an advanced IPv6 ACL
3. Add a rule for an advanced IPv6 ACL.
4. Click Add.
Table 138 Configuration items
Item Descri
p
tion
Select Access Control List (ACL) Select the advanced IPv6 ACL for which you want to configure rules.
Rule ID
Select the Rule ID box and enter a number for the rule.
If you do not specify the rule number, the system will assign one
automatically.
IMPORTANT:
If the rule number you specify already exists, the following operations
modify the configuration of the rule.
Operation
Select the operation to be performed for IPv6 packets matching the
rule.
• Permit—Allows matched packets to pass.
• Deny—Drops matched packets.

HP 1910 Specifications

General

Model	HP 1910
Category	Switch
Port Type	10/100/1000BASE-T
Layer	Layer 2
PoE Support	No
MAC Address Table Size	8K entries
VLAN Support	Yes
Management	Web-based GUI
Switching Capacity	56 Gbps
Forwarding Rate	41.7 Mpps
Jumbo Frame Support	Yes
Ports	24
