528
Figure 510 Port Setup tab
3. Configure the PoE ports as described in Table 158.
4. Click Apply.
Table 158 Configuration items
Item Descri
Select Port Select ports to be configured. They will be displayed in the Selected Ports area.
Power State
Enable or disable PoE on the selected ports.
• System does not supply power to or reserve power for the PD connected to a PoE
port if the PoE port is not enabled with the PoE function.
• You are allowed to enable PoE for a PoE port if the PoE port will not result in PoE
power overload; otherwise, you are not allowed to enable PoE for the PoE port.
By default, PoE is disabled on a PoE port.
IMPORTANT:
PSE power overload—When the sum of the power consumption of all ports exceeds
the maximum power of PSE, the system considers the PSE is overloaded.
Power Max
Set the maximum power for the PoE port.
Maximum PoE port power is the maximum power that the PoE port can provide to
the connected PD. If the power required by the PD is larger than the maximum PoE
port power, the PoE port will not supply power to the PD.
By default, a PoE port can supply a maximum power of 30,000 milliwatts.
