HP 5800 Series User Manual

201
Field Description
LB Base Initial label of the label block
LocPref Local preference
# Display detailed information about VPLS peer 3.3.3.9 in the BGP routing table.
<Sysname> display bgp vpls peer 3.3.3.9 verbose
Peer: 3.3.3.9 Local: 2.2.2.9
Type: IBGP link
BGP version 4, remote router ID 3.3.3.9
BGP current state: Established, Up for 01h06m42s
BGP current event: KATimerExpired
BGP last state: OpenConfirm
Port: Local - 1040 Remote - 179
Configured: Active Hold Time: 180 sec Keep Alive Time:60 sec
Received : Active Hold Time: 180 sec
Negotiated: Active Hold Time: 180 sec Keep Alive Time:60 sec
Peer optional capabilities:
Peer support bgp multi-protocol extended
Peer support bgp route refresh capability
Graceful Restart Capability: received
Restart Timer Value of Peer: 150 seconds
Forwarding State preserved by Peer for following Address families:
IPv4 Unicast
VPLS
Address family IPv4 Unicast: advertised and received
Address family VPLS: advertised and received
Received: Total 26 messages, Update messages 2
Sent: Total 28 messages, Update messages 2
Maximum allowed prefix number: 4294967295
Threshold: 75%
Minimum time between advertisement runs is 15 seconds
Optional capabilities:
Route refresh capability has been enabled
Connect-interface has been configured
Peer Preferred Value: 0
BFD: Enabled
Routing policy configured:
No routing policy is configured
Table 76 Command output
Field Description
Peer IP address of the peer.
Local IP address of the local router.
Type BGP type.
BGP version 4 BGP version information.

HP 5800 Series Specifications

General

MAC Address Table Size	32, 000 entries
Uplink Ports	2 or 4 SFP+ 10GbE ports
Routing Protocol	BGP, IS-IS
Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 95% (noncondensing)
PoE	Optional
Power Supply	Redundant power supply (optional)
