HP 5800 Series User Manual

347
Local AS number : 200
Total number of peers : 1 Peers in established state : 0
Peer AS MsgRcvd MsgSent OutQ PrefRcv Up/Down State
192.168.1.40 100 0 0 0 0 00:02:10 Active
Table 135 Command output
Field Description
Peer IP address of the peer
AS AS number of the peer
MsgRcvd Number of messages received
MsgSent Number of messages sent
OutQ Number of messages to be sent to the peer
PrefRcv Number of prefixes received
Up/Down Duration of the BGP session in the current state
State Current state of the peer
# D i s p l a y t h e d e t a i l e d i n f o rm a t i o n o f t h e B G P V P N v 6 p e e r 1.1.1.1.
<Sysname> display bgp vpnv6 all peer 1.1.1.1 verbose
Peer: 1.1.1.1 Local: 2.2.2.2
Type: IBGP link
BGP version 4, remote router ID 1.1.1.1
BGP current state: Established, Up for 00h46m01s
BGP current event: RecvKeepalive
BGP last state: OpenConfirm
Port: Local - 1039 Remote - 179
Configured: Active Hold Time: 180 sec Keepalive Time:60 sec
Received : Active Hold Time: 180 sec
Negotiated: Active Hold Time: 180 sec
Peer optional capabilities:
Peer support bgp multi-protocol extended
Peer support bgp route refresh capability
Address family IPv4 Unicast: advertised and received
Address family VPNv6: advertised and received
Received: Total 52 messages, Update messages 2
Sent: Total 65 messages, Update messages 5
Maximum allowed prefix number: 150000
Threshold: 75%
Minimum time between advertisement runs is 15 seconds
Optional capabilities:
ORF advertise capability based on Prefix(type 64):
Local: both
Negotiated: send

HP 5800 Series Specifications

General

MAC Address Table Size	32, 000 entries
Uplink Ports	2 or 4 SFP+ 10GbE ports
Routing Protocol	BGP, IS-IS
Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 95% (noncondensing)
PoE	Optional
Power Supply	Redundant power supply (optional)
