HP 8360 B Series User Manual

l FM:COUPling ACIDC
l FM : COUPling?
Sets and queries the FM input coupling mode.
The *RST value is AC.
l FM[:DEViationl <num>[freq suffix>] IMAXimumlMINimum
l FM[:DEViation]? [MAXimumlMINimum]
Sets and queries the peak FM deviation (in Hz) when the internal
FM generator is used. After *RST, the value is 1 MHz.
l FM:FILTer:HPASs <num>[freq suffix’lMAXimumlMINimum
l FM : FILTer : HPASs? [MAXimum I MINimuml
Sets and queries the FM AC bandwidth. There are only two
positions to the bandwidth, < 20 Hz and > 100 kHz, but any
numeric is accepted. The value is compared to 1 kHz and the correct
position is determined (> 1 kHz sets the position to 100 kHz and
5 1 kHz sets the position to 20 Hz). After *RST, the value is
100 kHz.
l FM:INTernal:FREQuency <num>[freq suffix] 1MAXimumlMINimum
l FM:INTernal:FREQuency? [MAXimumlMINimuml
Sets and queries the frequency (in Hz) of the internal FM source.
After ‘RST, the value is 1 MHz.
l FM:INTernal:FUNCtion SINusoidlSQUarelTRIaglelRAMPlNOISe
l FM : INTernal : FUNCt ion?
Sets and queries the waveform of the internal FM source.
After *RST, the value is SINusoid.
l FM:SOURce INTernallEXTernal
l FM:SOURce?
Sets and queries the source of the FM modulating signal.
After ‘RST, the value is EXTernal.
l FM:SENSitivity Cnum>Cfreqsuffix/VlIMAXimumlMINimum
l FM:SENSitivity? [MAXimumlMINimuml
Sets and queries the FM Input sensitivity.
The *RST value is MAX (10 MHz/V) .
l FM:STATe ONlOFFlllO
l FM : STATe?
Sets and queries the FM modulation state.
After *RST, the value is OFF.
S-34 Operating and Programming Reference
