Alloc Power
The maximum amount of PoE power allocated for that port (expressed in watts).Default: 17
watts for PoE; 33 watts for PoE+.
Actual Power
The power actually being used on that port.
Configured Type
If configured, shows the user-specified identifier for the port. If not configured, this field is
empty.
Detection Status • Searching: The port is trying to detect a PD connection.
• Delivering: The port is delivering power to a PD.
• Disabled: On the indicated port, either PoE support is disabled or PoE power is enabled
but the PoE module does not have enough power available to supply the port's power
needs.
• Fault: The switch detects a problem with the connected PD.
• Other Fault: The switch has detected an internal fault that prevents it from supplying
power on that port.
Power Class
Shows the 802.3af power class of the PD detected on the indicated port. Classes include:
• 0: 0.44 to 12.95 watts can be drawn by the PD. Default class.
• 1: 0.44 to 3.84 watts
• 2: 3.84 to 6.49 watts
• 3: 6.49 to 12.95 watts
• 4: For PoE+; up to 25.5 watts can be drawn by the PD
The show power-over-ethernet brief displays this output:
show power-over-ethernet brief command output
switch(config)# show power-over-ethernet brief
Status and Counters - System Power Status
System Power Status : No redundancy
PoE Power Status : No redundancy
Available: 600 W Used: 9 W Remaining: 591 W
Module A Power
Available: 408 W Used: 9 W Remaining: 399 W
POE | Power Power Alloc Alloc Actual Configured Detection Power
Port | Enable Priority By Power Power Type Status Class
----- + ------- --------- ----- ------ ------ ----------- ---------- ----
A1 | Yes low usage 17 W 0.0 W Searching 0
A2 | Yes low usage 17 W 0.0 W Searching 0
A3 | Yes low usage 17 W 0.0 W Searching 0
A4 | Yes low usage 17 W 0.0 W Searching 0
A5 | Yes low usage 17 W 0.0 W Searching 0
A6 | Yes low usage 17 W 8.4 W Delivering 2
A7 | Yes low usage 17 W 0.0 W Searching 0
A8 | Yes low usage 17 W 0.0 W Searching 0
A9 | Yes low usage 17 W 0.0 W Searching 0
120 Aruba 2930F / 2930M Management and Configuration Guide
for ArubaOS-Switch 16.08
