I 11/30/16 14:03:08 00070 chassis: AM1: Fan OK: Fan: 3 Failures: 1

Shown is a fan-tray fan-fault (fan number 3) failure. The event is issued as a "Warning" (w).

W 11/30/16 14:02:38 00070 chassis: AM1: Fan failure: Fan: 3 Failures: 1

Chapter 12 Monitoring and Analyzing Switch Operation 457
