Alarm Description
TX power high TX power is high
TX power low TX power is low
Temp high Temperature is high
Temp low Temperature is low
An Example: of the output for the show interfaces transceiver [port-list] detail for a 1000SX transceiver is shown
below.
Detailed information for a 1000SX Mini-GBIC transceiver
switch(config)# show interfaces transceiver 21 detail
Transceiver in 21
Interface index : 21
Type : 1000SX
Model : J4858C
Connector type : LC
Wavelength : 850nm
Transfer distance : 300m (50um), 150m (62.5um),
Diagnostic support : DOM
Serial number : MY050VM9WB
Status
Temperature : 50.111C
Voltage : 3.1234V
TX Bias : 6mA
TX Power : 0.2650mW, -5.768dBm
RX Power : 0.3892mW, -4.098dBm
Time stamp : Mon Mar 7 14:22:13 2011
An Example: of the output for a 10GbE-LR transceiver is shown below.
Detailed information for a 10GbE-LR transceiver
switch(config)# show interfaces transceiver 23 detail
Transceiver in 23
Interface Index : 24
Type : 10GbE-LR
Model : J8437A
Connector type : SC
Wavelength : Channel #0: 1310nm, #1:0nm, #2:0nm, #3:0nm
Transfer distance : 10000m (SM)
Diagnostic support: DOM
Serial number : ED456SS987
Status
Temperature : 32.754C
TX Bias : 42.700mA
TX Power : 0.5192mW, -2.847dBm
RX Power : 0.0040mW, -23.979dBm
Recent Alarms:
484 Aruba 2930F / 2930M Management and Configuration Guide
for ArubaOS-Switch 16.08
