Component identification 12
Node rear panel components
• 1U node rear panel components
Item
Description
1
Node serial number and iLO label pull tab
2
SUV connector
3
USB 3.0 connector
4
Dedicated iLO port (optional)
5
NIC connector 1
6
NIC connector 2
• 2U node rear panel components
Item
Description
1
Node serial number and iLO label pull tab
2
SUV connector
3
USB 3.0 connector
4
Dedicated iLO port (optional)
5
NIC connector 1
6
NIC connector 2
