Component identification 8
Component identification
Chassis front panel components
• HPE Apollo r2200 Chassis
Item Description
1
Left bezel ear
2
Low-profile LFF hot-plug drives
3
Right bezel ear
4
Chassis serial label pull tab
• HPE Apollo r2600 Chassis
Item Description
1
Left bezel ear
2
SFF HPE SmartDrives
3
Right bezel ear
4
Chassis serial label pull tab
5
Non-removable bezel blank

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HPE Apollo 2000 and is the answer not in the manual?

HPE Apollo 2000 Specifications

General IconGeneral
Form Factor2U
Memory TypeDDR4
Max Processors2
Memory Slots16 DIMM slots per server tray
Storage OptionsSAS, SATA
NetworkingFlexibleLOM
Network1/10/25/40/100 GbE options
Power SupplyRedundant Power Supplies
Power Supply Options1600W
Operating System SupportMicrosoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
StorageUp to 24 drives
