HPE Apollo 2000

Hardware options installation 78
Maximum memory capacity
Maximum memory capacity is a function of DIMM capacity, number of installed DIMMs, memory type, and
number of installed processors.
Maximum memory capacity - Intel Xeon E5-2600 v3 processor installed
DIMM type DIMM rank Capacity (GB)
Maximum capacity for
one processor (GB)
Maximum capacity for two
processors (GB)
RDIMM
Single-rank
4
32
64
RDIMM
Single-rank
8
64
128
RDIMM
Dual-rank
8
64
128
RDIMM
Dual-rank
16
128
256
LRDIMM
Dual-rank
16
128
256
RDIMM
Dual-rank
32
256
512
LRDIMM
Quad-rank
32
256
512
Maximum memory capacity - Intel Xeon E5-2600 v4 processor installed
DIMM type DIMM rank Capacity (GB)
Maximum capacity for
one processor (GB)
Maximum capacity for two
processors (GB)
RDIMM
Single-rank
8
64
128
RDIMM
Single-rank
16
128
256
RDIMM
Dual-rank
16
128
256
RDIMM
Dual-rank
32
256
512
LRDIMM
Dual-rank
32
256
512
LRDIMM
Quad-rank
64
512
1024
SmartMemory
SmartMemory authenticates and unlocks certain features available only on Qualified memory and verifies
whether installed memory has passed Hewlett Packard Enterprise qualification and test processes.
Qualified memory is performance-tuned for ProLiant and BladeSystem servers and provides future
enhanced support through Active Health and manageability software.
Memory subsystem architecture
The memory subsystem in this node is divided into channels. Each processor supports four channels, and
each channel supports two DIMM slots, as shown in the following table.
Channel Population order Slot number
1
A
E
8
7
2
B
F
6
5
3
C
G
1
2
4
D
H
3
4
For the location of the slot numbers, see "DIMM slot locations (on page 17)."
