Hardware options installation 77
• Intel Xeon E5-2600 v3 processors are optimized for:
o Single-rank and dual-rank PC4-2133 (DDR4-2133) RDIMMs operating at up to 2133 MT/s
o Dual-rank and quad-rank PC4-2133 (DDR4-2133) LRDIMMs operating at up to 2133 MT/s
• Intel Xeon E5-2600 v4 processors are optimized for:
o Single-rank and dual-rank PC4-2400T (DDR4-2400) RDIMMs operating at up to 2400 MT/s
o Dual-rank and quad-rank PC4-2400T (DDR4-2400) LRDIMMs operating at up to 2400 MT/s
DIMM specifications
DIMM specifications - Intel Xeon E5-2600 v3 processor installed
Type
Rank
Capacity (GB)
Native speed (MT/s)
Voltage
RDIMM
Single
4
2133
STD
RDIMM
Single
8
2133
STD
RDIMM
Dual
8
2133
STD
RDIMM
Dual
16
2133
STD
LRDIMM
Dual
16
2133
STD
RDIMM
Dual
32
2133
STD
LRDIMM
Quad
32
2133
STD
DIMM specifications - Intel Xeon E5-2600 v4 processor installed
Type Rank Capacity (GB) Native speed (MT/s) Voltage
RDIMM
Single
8
2400
STD
RDIMM
Single
16
2400
STD
RDIMM
Dual
16
2400
STD
RDIMM
Dual
32
2400
STD
LRDIMM
Dual
32
2400
STD
LRDIMM
Quad
64
2400
STD
Populated DIMM speed (MT/s)
Operating memory speed is a function of rated DIMM speed, the number of DIMMs installed per channel,
processor model, and the speed selected in the BIOS/Platform Configuration (RBSU) of the UEFI System
Utilities ("HPE UEFI System Utilities" on page 154).
Populated DIMM speed - Intel Xeon E5-2600 v3 processor installed
Type Rank
1 DIMM per channel
(MT/s)
2 DIMMs per
channel (MT/s)
RDIMM
Single
2133
2133
RDIMM
Dual
2133
2133
LRDIMM
Dual
2133
2133
LRDIMM
Quad
2133
2133
Populated DIMM speed - Intel Xeon E5-2600 v4 processor installed
Type Rank
1 DIMM per channel
(MT/s)
2 DIMMs per
channel (MT/s)
RDIMM
Single
2400
2133
RDIMM
Dual
2400
2133
LRDIMM
Dual
2400
2400
LRDIMM
Quad
2400
2400
