Operations 49
o
1U node
o 2U node
CAUTION:
To prevent improper cooling and thermal damage, do not operate the node unless
all PCI riser cages or rear
I/O blanks are installed, and do not operate the node unless all PCI
slots have either an expansion slot cover or an expansion board installed.
Single-slot 1U node right PCI riser cage assemblies
NOTE: Single-
slot 1U node right PCI riser cage assemblies feature different riser boards. For
more information on the riser board slot specifications, see "PCIe riser board slot definitions
(on page 26)."
To remove the component:
1. Power down the node (on page 32).
2. Disconnect all peripheral cables from the node.
3. Remove the node from the chassis (on page 32).
