Component identification 16
Mini-SAS connector 2 (SATA x4)
PCIe x24 riser board connector*
Dedicated iLO port connector
PCIe x16 riser board connector*
18
* For more information on the riser board slots supported by the onboard PCI riser connectors, see "PCIe riser board
slot definitions (on page 26)."
System maintenance switch
Position Default Function
S1
Off = iLO security is enabled.
On = iLO security is disabled.
S2
Off = System configuration can be
changed.
On = System configuration is locked.
S5
Off = Power-on password is enabled.
On = Power-on password is disabled.
S6
On = ROM reads system
configuration as invalid.
S7
Off = Set default boot mode to UEFI.
On = Set default boot mode to legacy.
To access the redundant ROM, set S1, S5, and S6 to On.
When the system maintenance switch position 6 is set to the On position, the system is prepared to erase
all system configuration settings from both CMOS and NVRAM.
CAUTION: Clearing CMOS, NVRAM, or both deletes configuration information. Be sure to
configure the node properly to prevent data loss.
IMPORTANT:
Before using the S7 switch to change to Legacy BIOS Boot Mode, be sure the
HPE Dynamic Smart Array B140i Controller is disabled. Do not use the B140i controller when
the node is in Legacy BIOS Boot Mode.
