Hardware options installation 105
o
The mixing of different accelerator models is not supported.
For more information on the riser board slot specifications, see "PCIe riser board slot definitions (on page
26)."
Supported riser cage assemblies and accelerator power cables
FlexibleLOM 2U node riser cage assembly (PN 798184-B21)
Single accelerator
options
Power cable 2-pin adapter cable
Intel Xeon Phi
Coprocessor 5110P
AMD FirePro S9150
GPU
NVIDIA Quadro K4200
GPU Accelerator
NVIDIA Tesla K40 GPU
Accelerator
800288-001
Three-slot PCI riser cage assembly (PN 798186-B21) and Three-slot GPU-direct PCI riser cage
assembly (PN 798188-B21)
Dual accelerator
Power cable 2-pin adapter cables
Intel Xeon Phi
Coprocessor 5110P
AMD FirePro S9150
GPU
NVIDIA Tesla K40 GPU
Accelerator
Both 825634-001 and
825635-001 are required
NVIDIA GRID K2
Reverse Air Flow GPU
Accelerator*
Both 825634-001 and
825635-001 are required
805206-001 required for each accelerator
* A single accelerator option is supported.
Three-slot GPU-direct with re-timer PCI riser cage assembly (PN 827353-B21)
Dual accelerator
options
Power cable 2-pin adapter cables
AMD FirePro S7150
GPU
Both 825634-001 and
825635-001 are required
NVIDIA Tesla K80 GPU
Accelerator*
NVIDIA Tesla M60 GPU
Accelerator*
Both 825636-001 and
825637-001 are required
* A single accelerator option is supported.
For more information, see "Accelerator cabling (on page 144)."
Installing one accelerator in a FlexibleLOM 2U node riser cage
assembly
For more information about product features, specifications, options, configurations, and compatibility,
see the product QuickSpecs on the Hewlett Packard Enterprise website (http://www.hpe.com/info/qs).
