Operations 51
5.
Remove the FlexibleLOM 1U node riser cage assembly.
CAUTION:
To prevent improper cooling and thermal damage, do not operate the node unless
all PCI riser cages or rear I/O blanks are installed, and do not operate the node unless all PCI
slots have either an expansion slot cover or an expansion board installed.
Single-slot 2U node PCI riser cage assembly
To remove the component:
1. Power down the node (on page 32).
2. Disconnect all peripheral cables from the node.
3. Remove the node from the chassis (on page 32).
4. Place the node on a flat, level surface.
5. Remove the FlexibleLOM 2U node riser cage assembly (on page 52).
6. Remove the single-slot 2U node PCI riser cage assembly.
