Hardware options installation 69
o
SFF SmartDrive
o Low-profile LFF hot-plug drive
5. Determine the status of the drive from the drive LED definitions ("Hot-plug drive LED definitions" on
page 22).
6. If removed, install the security bezel ("Security bezel option" on page 67).
For information on drive bay mapping in the HPE Apollo r2800 Chassis and the factory default
configuration, see "Drive bay mapping for the HPE Apollo r2800 Chassis (on page 65)."
To configure arrays, see the HPE Smart Storage Administrator User Guide on the Hewlett Packard
Enterprise website (http://www.hpe.com/info/smartstorage/docs).
Node blank
For more information about product features, specifications, options, configurations, and compatibility,
see the product QuickSpecs on the Hewlett Packard Enterprise website (http://www.hpe.com/info/qs).
