HPE Apollo 2000 User Manual

Operations 33
CAUTION: To avoid damage to the node, always support the bottom of the node when
removing it from the chassis.
1. Power down the node (on page 32).
2. Disconnect all peripheral cables from the node.
3. Remove the node from the chassis:
a. Loosen the thumbscrew.
b. Pull back the handle and remove the node.
— 1U node
— 2U node
CAUTION: To avoid damage to the device, do not use the removal handle to carry it.
4. Place the node on a flat, level surface.

HPE Apollo 2000 Specifications

General

Form Factor	2U
Memory Type	DDR4
Max Processors	2
Memory Slots	16 DIMM slots per server tray
Storage Options	SAS, SATA
Networking	FlexibleLOM
Network	1/10/25/40/100 GbE options
Power Supply	Redundant Power Supplies
Power Supply Options	1600W
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
Storage	Up to 24 drives
