HPE Apollo 2000 - Page 46

Operations 46
o
1U bayonet board
IMPORTANT: If connecting a SATA or Mini-SAS cable to the 2U bayonet board, route the
cable under the padding before installing the 2U bayonet board bracket.
o 2U bayonet board
2. Install the bayonet board bracket onto the bayonet board.
