Displaying and maintaining MPLS
Execute display commands in any view and reset commands in user view.
Task
Command
Display MPLS interface information.
display mpls interface
[ interface-type interface-number ]
Display usage information about MPLS
labels.
display mpls label
{ label-value1 [
to
label-value2 ] |
all
}
Display LSP information.
display mpls lsp
[
egress
|
in-label
label-value |
ingress
|
outgoing-interface
interface-type interface-number |
protocol
{
bgp
|
ldp
|
local
|
rsvp-te
|
static
|
static-cr
} |
transit
]
[
vpn-instance
vpn-instance-name ] [ ipv4-dest mask-length |
ipv6
[ ipv6-dest prefix-length ] ] [
verbose
]
Display MPLS Nexthop Information
Base (NIB) information.
display mpls nib
[ nib-id ]
Display usage information about NIDs.
display mpls nid
[ nid-value1 [
to
nid-value2 ] ]
Display LSP statistics.
display mpls lsp statistics
Display MPLS summary information.
display mpls summary
Display ILM entries.
display mpls forwarding ilm
[ label ] [
slot
slot-number ]
Display NHLFE entries.
display mpls forwarding nhlfe
[ nid ] [
slot
slot-number ]
Clear MPLS forwarding statistics for the
specified LSPs.
reset mpls statistics
{
all
| [
vpn-instance
vpn-instance-name ]
{
ipv4
ipv4-destination mask-length |
ipv6
ipv6-destination
prefix-length } |
static
|
te
ingress-lsr-id tunnel-id }
