28
Figure 15 Label advertisement control diagram
A label advertisement policy on an LSR and a label acceptance policy on its upstream LSR can
achieve the same purpose. If downstream LSRs support label advertisement control, use label
advertisement policies as a best practice to reduce network load.
Before you configure an LDP label advertisement policy, create an IP prefix list. For information
about IP prefix list configuration, see Layer 3—IP Routing Configuration Guide.
To configure a label advertisement policy:
1. Enter system view.
N/A
2. Enter LDP view or enter
LDP-
view.
• Enter LDP view:
mpls ldp
• Enter LDP-VPN instance view:
a. mpls ldp
b. vpn-instance
vpn-instance-name
N/A
3. Configure a label
advertisement policy.
advertise-label prefix-list
prefix-list-name [
peer
peer-prefix-list-name ]
B
y default, LDP advertises all
label mappings permitted by the
LSP generation policy to all
peers.
Configuring a label acceptance policy
A label acceptance policy uses an IP prefix list to control the label mappings received from a peer.
As shown in Figure 16, LSR A uses an IP prefix list to filter label mappings from LSR B, and it does
not filter label mappings from LSR C.
LSR C
LSR ALSR B
Advertise label
mappings permitted
by IP prefix list C
Advertise label
mappings permitted
by IP prefix list B
