73
Step
Command
Remarks
OSPF and IS-IS will include
the MPLS TE tunnel in route
calculation.
4.
Assign a metric to the
MPLS TE tunnel.
mpls te igp metric
{
absolute
value |
relative
value }
By default, the metric of an
MPLS TE tunnel equals its IGP
metric.
Configuring forwarding adjacency
To use forwarding adjacency, you must establish two MPLS TE tunnels in opposite directions
between two nodes, and configure forwarding adjacency on both the nodes.
To configure forwarding adjacency:
Step
Command
Remarks
1. Enter system view.
system-view
N/A
2.
Enter MPLS TE tunnel
interface view.
interface tunnel
tunnel-number
[
mode
mpls-te
]
N/A
3.
Enable forwarding
adjacency.
mpls te igp advertise
[
hold-time
value ]
By default, forwarding adjacency
is disabled.
Configuring a bidirectional MPLS TE tunnel
Before you create a bidirectional MPLS TE tunnel, complete the following tasks:
• Disable the PHP function on both ends of the tunnel.
• To set up a bidirectional MPLS TE tunnel in co-routed mode, you must specify the signaling
protocol as RSVP-TE, and use the mpls te resv-style command to configure the resources
reservation style as FF for the tunnel.
• To set up a bidirectional MPLS TE tunnel in associated mode and use RSVP-TE to set up one
CRLSP of the tunnel, you must use the mpls te resv-style command to configure the
resources reservation style as FF for the CR-LSP.
To create a bidirectional MPLS TE tunnel, create an MPLS TE tunnel interface on both ends of the
tunnel and enable the bidirectional tunnel function on the tunnel interfaces:
• For a co-routed bidirectional tunnel, configure one end of the tunnel as the active end and the
other end as the passive end, and specify the reverse CR-LSP at the passive end.
• For an associated bidirectional tunnel, specify a reverse CR-LSP at both ends of the tunnel.
To configure the active end of a co-routed bidirectional MPLS TE tunnel:
Step
Command
Remarks
1. Enter system view.
system-view
N/A
2.
Enter MPLS TE tunnel
interface view.
interface tunnel
tunnel-number
[
mode
mpls-te
]
N/A
3. Configure a co-routed
bidirectional MPLS TE tunnel
and specify the local end as
the active end of the tunnel.
mpls te bidirectional
co-routed
active
By default, no bidirectional tunnel
is configured, and tunnels
established on the tunnel
interface are unidirectional MPLS
TE tunnels.
To configure the passive end of a co-routed bidirectional MPLS TE tunnel:
