HPE FlexNetwork 5510 HI Series Mpls Configuration Guide

129
Step
Command
Remarks
1. Enter system view.
system-view
N/A
2. Create a static CRLSP.
• Configure the ingress node:
static-cr-lsp ingress lsp-name
{ nexthop next-hop-addr |
outgoing-interface interface-type
interface-number } out-label
out-label-value [ bandwidth [ ct0 |
ct1 | ct2 | ct3 ] bandwidth-value ]
• Configure a transit node:
static-cr-lsp transit lsp-name
in-label in-label-value { nexthop
next-hop-addr | outgoing-interface
interface-type interface-number }
out-label out-label-value
[ bandwidth [ ct0 | ct1 | ct2 | ct3 ]
bandwidth-value ]
• Configure the egress node:
static-cr-lsp egress lsp-name
in-label in-label-value
Use one command according
to the position of a device on
the network.
By d
efault, no static CRLSP
exists.
Do not configure the next hop
address as a local public IP
address when configuring the
static CRLSP on the ingress
node or a transit node.
You do not need to execute the
static-cr-lsp egress
command on the egress node
if the outgoing label configured
on the penultimate hop of the
static CRLSP is 0 or 3.
Displaying static CRLSPs
Execute display commands in any view.
Task
Command
Display static CRLSP
information.
display mpls static-cr-lsp
[
lsp-name
lsp-name ] [
verbose
]
Static CRLSP configuration example
Network requirements
Switch A, Switch B, and Switch C run IS-IS.
Establish an MPLS TE tunnel over a static CRLSP from Switch A to Switch C.
