64
TE traffic.
traffic is 0.
4. Configure the maximum
reservable bandwidth.
•
Configure the maximum reservable
bandwidth of the link (BC 0) and BC 1
in RDM model of
DS-TE:
mpls te max-reservable-bandwidth
bandwidth-value [ bc1
bc1-bandwidth ]
•
Configure the maximum reservable
bandwidth of the link and the BCs in
MAM model of the IETF DS-TE:
mpls te max-reservable-bandwidth
mam bandwidth-value { bc0
bc0-bandwidth | bc1 bc1-bandwidth |
bc2 bc2-bandwidth | bc3
bc3-bandwidth } *
• Configure
bandwidth of the link and the BCs in
RDM model of the IETF DS-TE:
mpls te max-reservable-bandwidth
rdm bandwidth-value [ bc1
bc1-bandwidth ] [ bc2 bc2-bandwidth ]
[
bc3-bandwidth ]
Use one command according
to the DS-TE mode and BC
"Configuring DS-TE."
By default, the maximum
reservable bandwidth of a
link is 0 kbps and each BC is
0 kbps.
In RDM model, BC 0 is the
bandwidth of a link.
5.
attribute.
mpls te link-attribute
attribute-value
By default, the link attribute
value is 0x00000000.
Advertising link TE attributes by using IGP TE extension
Both OSPF and IS-IS are extended to advertise link TE attributes. The extensions are called OSPF
TE and IS-IS TE. If both OSPF TE and IS-IS TE are available, OSPF TE takes precedence.
Configuring OSPF TE
OSPF TE uses Type-10 opaque LSAs to carry the TE attributes for a link. Before you configure
OSPF TE, you must enable opaque LSA advertisement and reception by using the
opaque-capability enable command. For more information about opaque LSA advertisement and
reception, see Layer 3—IP Routing Configuration Guide.
MPLS TE cannot reserve resources and distribute labels for an OSPF virtual link, and cannot
establish a CRLSP through an OSPF virtual link. Therefore, make sure no virtual link exists in an
OSPF area before you configure MPLS TE.
To configure OSPF TE:
1. Enter system view.
N/A
2. Enter OSPF view.
ospf
[ process-id ] N/A
3. Enable
opaque LSA
advertisement and
reception.
opaque-capability enable
By default,
advertisement and reception are
enabled.
For more information about this
command, see Layer 3—IP Routing
Command Reference.
4. Enter area view.
area
area-id N/A
