• ITU-T Recommendation Y.1720, Protection switching for MPLS networks
MPLS TE configuration task list
To configure an MPLS TE tunnel to use a static CRLSP, complete the following tasks:
1. Enable MPLS TE on each node and interface that the MPLS TE tunnel traverses.
2. Create a tunnel interface on the ingress node of the MPLS TE tunnel, and specify the tunnel
destination address (the address of the egress node).
3. Create a static CRLSP on each node that the MPLS TE tunnel traverses.
For information about creating a static CRLSP, see "Configuring a static CRLSP."
4. On the ingress node of the MPLS TE tunnel, configure the tunnel interface to reference the
created static CRLSP.
5. On the ingress node of the MPLS TE tunnel, configure static routing or automatic route
advertisement to direct traffic to the MPLS TE tunnel.
To configure an MPLS TE tunnel to use a CRLSP dynamically established by RSVP-TE, complete
the following tasks:
1. Enable MPLS TE and RSVP on each node and interface that the MPLS TE tunnel traverses.
For information about enabling RSVP, see "Configuring RSVP."
2. Create a tunnel interface on the ingress node of the MPLS TE tunnel, specify the tunnel
destination address (the address of the egress node), and configure the MPLS TE tunnel
constraints (such as the tunnel bandwidth constraints and affinity) on the tunnel interface.
3. Configure the link TE attributes (such as the maximum link bandwidth and link attribute) on
each interface that the MPLS TE tunnel traverses.
4. Configure an IGP on each node that the MPLS TE tunnel traverses, and configure the IGP to
support MPLS TE, so that the nodes advertise the link TE attributes through the IGP.
5. On the ingress node of the MPLS TE tunnel, configure RSVP-TE to establish a CRLSP based
on the tunnel constraints and link TE attributes.
6. On the ingress node of the MPLS TE tunnel, configure static routing or automatic route
advertisement to direct traffic to the MPLS TE tunnel.
You can also configure other MPLS TE functions such as the DS-TE, automatic bandwidth
adjustment, and FRR as needed.
To configure MPLS TE, perform the following tasks:
(Required.) Enabling MPLS TE
(Required.) Configuring a tunnel interface
(Optional.) Configuring DS-TE
(Required.) Perform at least one of the following tasks to configure an MPLS TE tunnel:
• Configuring an MPLS TE tunnel to use a static CRLSP
• Configuring an MPLS TE tunnel to use a dynamic CRLSP
(Required.) Configuring traffic forwarding:
• Configuring static routing to direct traffic to an MPLS TE tunnel
• Configuring automatic route advertisement to direct traffic to an MPLS TE tunnel
(Optional.) Configuring a bidirectional MPLS TE tunnel
(Optional.) Configuring CRLSP backup
Only MPLS TE tunnels established by RSVP-TE support this configuration.
