196
Task
Command
Display BGP VPNv4 peer
information.
display bgp peer vpnv4
[
vpn-instance
vpn-instance-name ]
[ ip-address mask-length | { ip-address |
group-name
group-name }
log-info
| [ [ ip-address ]
verbose
] [
standby slot
slot-number ] ]
Display BGP VPNv4 routes.
display bgp routing-table vpnv4
[ [
route-distinguisher
route-distinguisher ] [ network-address [ { mask | mask-length }
[
longest-match
] ] | network-address [ mask | mask-length ]
advertise-info
|
as-path-acl
as-path-acl-number |
community-list
{ { basic-community-list-number | comm-list-name } [
whole-match
] |
adv-community-list-number } ] | [
vpn-instance
vpn-instance-name ]
peer
ip-address {
advertised-routes
|
received-routes
}
[ network-address [ mask | mask-length ] |
statistics
] |
statistics
]
[
standby slot
slot-number ]
Display incoming labels for BGP
IPv4 unicast routes.
display bgp routing-table ipv4
[
unicast
] [
vpn-instance
vpn-instance-name ]
inlabel
Display outgoing labels
for BGP
IPv4 unicast routes.
display bgp routing-table ipv4
[
unicast
] [
vpn-instance
vpn-instance-name ]
outlabel
[
standby slot
slot-number ]
Display incoming labels for BGP
VPNv4 routes.
display bgp routing-table vpnv4 inlabel
Display outgoing label
s for BGP
VPNv4 routes.
display bgp routing-table vpnv4 outlabel
[
standby slot
slot-number ]
Display BGP VPNv4 address
family update group information.
display bgp update-group vpnv4
[
vpn-instance
vpn-instance-name ] [ ip-address ]
Display OSPF sham link
information.
display ospf
[ process-id ]
sham-link
[
area
area-id ] [
standby slot
slot-number ]
For more information about the display ip routing-table, display bgp group vpnv4, display bgp
peer vpnv4, and display bgp update-group vpnv4 commands, see Layer 3—IP Routing
Command Reference.
MPLS L3VPN configuration examples
Configuring basic MPLS L3VPN
Network requirements
CE 1 and CE 3 belong to VPN 1. CE 2 and CE 4 belong to VPN 2.
VPN 1 uses route target attribute 111:1. VPN 2 uses route target attribute 222:2. Users of different
VPNs cannot access each other.
EBGP is used to exchange VPN routing information between CE and PE.
PEs use OSPF to communicate with each other and use MP-IBGP to exchange VPN routing
information.
