Huawei quidway s7700 Configuration Guide - Ethernet

Figure 3-9 Networking diagram for configuring VLAN transparent transport
SwitchA
SwitchB
Parent
Company
Subsidiary
Company1
Subsidiary
Company2
Subsidiary
Company3
Marketing
Department
VLAN10
Finance
Department
VLAN50
Technology
Department
VLAN20
Finance
Department
VLAN50
Finance
Department
VLAN50
Marketing
Department
VLAN10
Marketing
Department
VLAN10
Marketing
Department
VLAN10
Technology
Department
VLAN20
Technology
Department
VLAN20
Technology
Department
VLAN20
Pre-configuration Tasks
Before configuring VLAN transparent transport, complete the following task:
l 3.3 Dividing a LAN into VLANs
Data Preparation
To configure VLAN transparent transport, you need the following data.
No.
Data
1 VLAN ID and number of each port added to the VLAN
3.10.2 Enabling VLAN Transparent Transport
After VLAN transparent transport is enabled, the device directly forwards data from the specified
VLAN without processing the data.
Quidway S7700 Smart Routing Switch
Configuration Guide - Ethernet 3 VLAN Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
116

Huawei quidway s7700 Specifications

General

Hot Swappable Fans	Yes
IPv4 Routing	Yes
IPv6 Routing	Yes
MPLS	Yes
VLAN Support	Yes
QoS Support	Yes
Operating Temperature	0°C to 45°C
Operating Humidity	5% to 95% (non-condensing)
Product Type	Switch
Management	CLI, SNMP
Storage Temperature	-40°C to 70°C
Power Consumption	Varies by configuration
Slot Quantity	3 (S7703); 6 (S7706); 12 (S7712)
