Pre-configuration Tasks
Before configuring basic SEP functions, complete the following tasks:
l Establishing the ring networking
l Ensuring that the devices are powered on correctly and operate properly
Data Preparation
To configure basic SEP functions, you need the following data.
No. Data
1 SEP segment ID
2 ID of the control VLAN in the SEP segment
3 Role of each interface added to the SEP segment
10.2.2 Configuring an SEP Segment
SEP takes an SEP segment as a basic unit. An SEP segment is composed of multiple
interconnected Layer 2 switching devices configured with the same SEP segment ID and the
same control VLAN ID.
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
sep segment segment-id
An SEP segment is created and the view of the SEP segment is displayed.
Before deleting a created SEP segment, you need to check whether there is any interface added
to the SEP segment. If there is an interface added to the SEP segment, run the undo sep
segment segment-id command in the interface view to delete the interface from the SEP segment.
Otherwise, the SEP segment cannot be deleted.
----End
10.2.3 Configuring a Control VLAN
In a SEP segment, a control VLAN is used to transmit SEP packets but not service packets,
enhancing the security of SEP. Each SEP segment must be configured with a control VLAN.
After being added to a SEP segment configured with a control VLAN, an interface is added to
the control VLAN automatically.
Quidway S7700 Smart Routing Switch
Configuration Guide - Ethernet 10 SEP Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
507
