Procedure
l Run the display stp [ instance instance-id ] [ interface { interface-type interface-
number } ] [ brief ] command to view spanning-tree status and statistics.
----End
9.5 Configuring MSTP Protection Functions
MSTP protection functions are as follows, and you can configure one or more functions as
required.
9.5.1 Establishing the Configuration Task
Before configuring MSTP protection functions, familiarize yourself with the applicable
environment, complete the pre-configuration tasks, and obtain the required data. This will help
you complete the configuration task quickly and accurately.
Applicable Environment
MSTP provides the following protection functions, as listed in Table 9-6.
Table 9-6 MSTP protection
MSTP
Protection
Scenario Configuration Impact
BPDU
protection
An edge port changes to be a
non-edge port after
receiving a BPDU, which
triggers spanning tree
recalculation. If an attacker
keeps sending bogus BPDUs
to a switching device,
network flapping occurs.
After BPDU protection is enabled on the
switching device, the switching device shuts
down the edge port if the edge port receives
an RST BPDU, and notifies the NMS of the
shutdown event. The attributes of the edge
port are not changed.
TC protection Generally, after receiving
TC BPDUs (packets for
advertising network
topology changes), a
switching device needs to
delete MAC entries and ARP
entries. Frequent deletion
operations will exhaust CPU
resources.
TC protection is used to suppress TC-BPDUs.
The number of times that TC-BPDUs are
processed by a switching device within a
given time period is configurable. If the
number of TC-BPDUs that the switching
device receives within the given time exceeds
the specified threshold, the switching device
handles TC-BPDUs only for the specified
number of times. Excessive TC-BPDUs are
processed by the switching device as a whole
for once after the timeout period expires. This
protects the switching device from frequently
deleting MAC entries and ARP entries, thus
avoiding over-burden.
