EDGE Pro Ti CNC Instruction Manual 807660 129

Maintenance and Diagnostics

Plasma interface board (141267)

Table 28 Pinouts for J1 to J3

Pin no. Signal

J1 I/O terminal block

1 Start output+ (contact closure)

2 Start output- (contact closure)

3 +12 V output (maximum 50 mA)

4 Hold output+

5 Hold output-

J2 Negative electrode

1Arc voltage-

2Arc voltage-

J3 I/O terminal block

1 Transfer input+

2 Transfer input-

3Ground

4 Not used

5 Not used
