130 EDGE Pro Ti CNC Instruction Manual 807660
Maintenance and Diagnostics
Relay I/O board (141278)
Relay I/O board (141278)
Figure 69 Relay I/O board
1
OFF
2
3
J2 Lifter interface J3 Plasma interface
J11
I/O 7 – 9
J10
I/O 4 – 6
J12
I/O 10 – 12
J9
I/O 1 – 3
Switch 1
Configure I/O
J8 Digital I/O 1 – 24
J7
Clean and field
power
J1
To surge board
J5
To 60
VAC/VDC
power supply
J6
AV Utility
Refer to page 73 for more information about shared inputs
and input modes.
123
On
Use lower limit
switch
Upper limit
switch
Dry contact
inputs
(default)
Off
I/O 12
(default)
I/O 11
(default)
Sourced inputs
ON
Default settings for DIP switch
D26
D13
D22
D21
D20
D19
D18
D17
D16
D15
D14
D23
D24
D40
D50
D49
D48
D47
D46
D45
D44
D43
D42
D41
D41
D59
D58
D57
D56
D55
D61
D60
