134 EDGE Pro Ti CNC Instruction Manual 807660
Maintenance and Diagnostics
Relay I/O board (141278)
Table 35 Pinouts for J7 clean and field power
Table 36 Pinouts for J8 digital I/O 1 to 24
Pin no. Signal Pin no. Signal
1 +12 V 18 Field ground
2 Field ground 19 Regen active D
3 -12 V 20 Not connected
4 Field ground 21 Not connected
5 +5 V 22 Not connected
6 Field ground 23 Not connected
7 +24 V 24 Not connected
8 Field ground 25 Not connected
9 +24 V 26 Not connected
10 Field ground 27 Logic +5 V
11 Servo 1 fault 28 Logic ground
12 Field ground 29 Logic +12 V
13 Servo 2 fault 30 Logic ground
14 Field ground 31 Logic -12 V
15 Servo 3 fault 32 Logic ground
16 Field ground 33 Logic +5 V
17 Servo 4 fault 34 Logic ground
Pin no. Signal Pin no. Signal
1 Input 1 26 Output 13
2 Output 1 27 Regen active
3 Input 2 28 Output 14
4 Output 2 29 Input 15
5 Input 3 30 Not connected
6 Output 3 31 Input 16
7 Input 4 32 Not connected
8 Output 4 33 Axis 1 fault
9 Input 5 34 60 V inhibit
10 Output 5 35 Axis 2 fault
11 Input 6 36 Spare output
12 Output 6 37 Axis 3 fault
13 Input 7 38 Not connected
14 Output 7 39 Axis 4 fault
15 Input 8 40 Not connected
16 Output 8 41 E-stop active
17 Input 9 42 Not connected
18 Output 9 43 AC/DC power good
19 Input 10 44 Not connected
20 Output 10 45 Logic ground
21 Input 11, Upper limit 46 Not connected
