138 EDGE Pro Ti CNC Instruction Manual 807660
Maintenance and Diagnostics
4-axis DC servo board (141281)
Table 38 Axis fault LEDs
Table 39 Pinouts for J2 to J4
Table 40 Pinouts for J5 to MCC board
LED Color and condition When illuminated, these LEDs indicate that the servo amplifier for the
corresponding axis has shut down and that a fault is present, such as:
• Motor or cable short circuit or open circuit
• Excessive DC input voltage to the amplifier
• Amplifier is overheated
• Power up reset
D13 Red, axis 4 fault
D16 Red, axis 3 fault
D17 Red, axis 2 fault
D21 Red, axis 1 fault
Pin no. Signal Pin no. Signal
J2 Power distribution board J3 Terminal block
1 Field ground 1 +60 VDC
2 +24 V 2 60 V power ground
3 +5 V 3 Regen resistor
4 -12 V 4 Regen resistor
5+12 V
J4 Clean 5 V and 12 V in
6 Field ground 1 +5 VDC
2 Not connected
3+12 VDC
4 Ground
Pin no. Signal Pin no. Signal
1 Axis 1 enable 21 Not connected
2 Axis 2 enable 22 Not connected
3 Axis 3 enable 23 Not connected
4 Axis4enable 24 Not connected
5 Not connected 25 Not connected
6 Not connected 26 Logic ground
7 Watchdog enable 27 Logic ground
8 Axis 1A 28 Analog common
9 Axis 1B 29 Axis 1 analog
10 Axis 1Z 30 Axis 2 analog
11 Axis 2A 31 Axis 3 analog
12 Axis 2B 32 Axis 4 analog
13 Axis 2Z 33 Not connected
14 Axis 3A 34 Not connected
15 Axis 3B 35 Logic ground
16 Axis 3Z 36 Logic +5 V
17 Axis 4A 37 Logic +5 V
18 Axis 4B 38 Logic +12 V
19 Axis 4Z 39 Logic -12 V
20 Not connected 40 Logic ground
