MENU SCREEN OPERATION
New2001
D GPS TX mode
Sets the transmission of data from a connected GPS re-
ceiver ON and OFF.
When the position information is received from a connected
GPS receiver and the GPS Auto TX Timer setting (p. 106) is
set to a specifi c time, the transceiver automatically transmits
the current position and message at the set interval.
(default: DISABLE)
• DISABLE : Transmitting position data is disabled. (default)
• GPS : Transmitting position data in GPS mode.
• GPS-A : Transmitting position data in GPS-A mode.
• Sentence formatter setting
q Select “GPS” in GPS TX mode item, then push [ ](5)
‡
to
enter the sentence formatter selection.
w Rotate [DIAL]
†
to select the desired sentence formatter.
• RMC, GGA, GLL, GSA, VTG and GSV are selectable.
e Push [ ](5)
‡
to enter the desired sentence formatter se-
lection.
r Rotate [DIAL]
†
to select the setting.
• See next page for details.
t Push [ ](5) or [ ](6) to select ON/OFF.
y Rotate [DIAL]
†
to select next sentence and repeat steps
w to t, or push [MENU/
] to return to frequency in-
dication.
• Only four sentence formatters can be activated at same time.
DISABLE
GPS
GPS-A
GPS TX MODE
r
:GPS-A SET
DISABLE
GPS
GPS-A
GPS TX MODE
r
RMC:OFF
GGA:ON
GLL:OFF
GSA:OFF
VTG:OFF
GPS SENTENCE
r
RMC:OFF
GGA:ON
GLL:OFF
GSA:OFF
VTG:OFF
GPS SENTENCE
r
OFF
ON
RMC SENTENCE
r
OFF
ON
RMC SENTENCE
r
†
[DIAL] ↔ [ ](2)/[ ](8)
‡
[ ](5) ↔ [ ](6)
To Next Page
