OTHER FUNCTIONS
New2001
■ Tone frequency and DTCS code (Continued)
D Setting DTCS code for DTCS squelch or
beep
q Enter “DTCS CODE” in DUP/TONE... set mode. (p. 111)
w Rotate [DIAL]
†
to select the desired DTCS tone code.
• Each operating band and each memory channel have inde-
pendent settings.
• See page 111 for available DTCS codes for details.
e Push [ ](5) (or [ ](4)) to return to DUP/TONE… set
mode, and push [MENU/
] to return to frequency indi-
cation.
DTCS phase mode can be selected in “DTCS POLAR-
ITY” menu.
(p. 111)
■ Digital code and digital call
sign setting
D Setting digital code for digital code squelch
or beep
q Push [MAIN/DUAL] to select B band, then push and hold
[MODE](REC) for 1 sec. several times to select DV mode.
w Enter “DIGITAL CODE” in DV SET MODE.
(p. 100)
e Rotate [DIAL]
†
to select the desired digital code.
• Each operating band and each memory channel have inde-
pendent settings.
r Push [ ](5) (or [ ](4)) to return to DV SET MODE, and
push [MENU/
] to return to frequency indication.
❮MENU screen❯ ➪ ❮DV SET MODE❯ ➪ ❮DIGITAL CODE❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
DV VOICE M
SET MODE
r
DV SET MODE
***** MENU *****
0000
200200
500500
r
300300
DIGITAL CODEDIGITAL CODE
r
CALL SIGN
RX CALL S
MESSAGE/POS
***** MENU *****
r
U01
ABCDEF
500
r
300
YOUR CALL SIGN
r
M01
GHIJKL
500
r
300
MY CALL SIGN
❮MENU screen❯ ➪ ❮DUP/TONE...❯ ➪ ❮DTCS CODE❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
DV SET MODE
SCAN
r
DUP/TONE...
***** MENU *****
88.5
200
500
r
300
CTCSS TONE
88.5
200
500
r
300
REPEATER TONE
DV SET MODE
SCAN
r
DUP/TONE...
***** MENU *****
023023
200200
500500
r
300300
DTCS CODEDTCS CODE
