Icom IC-E92D Instruction Manual

118
13
OTHER FUNCTIONS
New2001
■ Transmitting a DTMF code
D Transmitting from DTMF memory
The selected DTMF code is transmitted at each push of the
[SQL] switch while transmitting.
The transmitting speed at which DTMF memories send
individual DTMF characters can be set in “DTMF SPEED”
menu.
(p. 111)
q Set the desired frequency. (p. 18)
w Push and hold [DTMF.M](9) for 1 sec. to enter DTMF
memory.
e Rotate [DIAL]
†
to select the desired DTMF memory chan-
nel.
r Push [
](5) to set the DTMF memory.
t Push [VFO] to exit DTMF memory.
y While pushing [PTT], push [SQL] to transmit the selected
DTMF code.
D Transmitting from DTMF memory via keypad
The selected DTMF memory can be transmitted via keypad
directly while transmitting. Pushing [1]–[9] or [0] to transmit
DTMF memory channel (Ch01–Ch09 or Ch10) respectively.
q Set the desired frequency. (p. 18)
w Enter “DTMF TX KEY” in DUP/TONE… set mode. (p. 112)
e Rotate [DIAL]
†
to select DTMF transmitting key
(DTMF–M) as below.
r Push [
](5) (or [ ](4)) to return to DUP/TONE… set
mode, and push [MENU/
] to return to frequency indi-
cation.
t While pushing [PTT], push the desired keys to transmit
the selected DTMF memory.
• [1]–[9] transmits “Ch01”–“Ch09” and [0] transmits “Ch10.”
MemoNameMemoName
PRIOPRIO WXWX EMREMR
DTCSDTCS
FMFM
A
43438 500500
PSKIPPSKIP
+DUP+DUP
µ
000000
5D28AB45D28AB4
The DTMF code is displayed here
when transmitting the code.
A
FM
438 500
PSKIP
[SQL]
[DIAL]
VFO
MHz
A
9
DTMF . M
CS
❮MENU screen❯ ➪ ❮DUP/TONE...❯ ➪ ❮DTMF TX KEY❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
DTMF-M
DTMF-M
KEY
KEY
DTMF TX KEY
DTMF TX KEY
r
