PANEL DESCRIPTION
New2001 New
■ Function display
q BATTERY INDICATOR (pgs. 10, 12)
➥ “
” (battery indicators) appear when the battery
pack is attached.
➥ “
” appears when the battery cells/pack must be
changed/charged.
➥ The indicators show “
,” “ ” and “ ” in se-
quence while charging the attached battery pack.
w DUPLEX INDICATOR (p. 32)
“ +DUP” appears when plus duplex, “–DUP” appears when
minus duplex is selected.
e PRIORITY WATCH INDICATOR (p. 90)
Appears when priority watch is in use.
r TONE INDICATOR
• While operating in FM/FM-N mode;
➥ “ TONE” appears while the subaudible tone encoder is
in use. (pgs. 30, 124)
➥ “ TSQL” appears while the tone squelch function is in
use. (p. 124)
➥ “ TSQL R” appears while the reverse tone squelch func-
tion is in use. (p. 124)
➥ “ DTCS” appears while the DTCS squelch function is in
use. (p. 124)
➥ “ DTCS R” appears while the reverse DTCS squelch
function is in use. (p. 124)
➥ “ S” appears with the “TSQL” or “DTCS” indicator
while the pocket beep function
(with CTCSS or DTCS) is
in use. (p. 125)
• Dualwatch indication
• Single band indication
MemoName
MemoName
µ
PRIO
PRIO
EMR
EMR
DSQL
DSQL
DV
DV
B
LOW
LOW
ATT
ATT
43
439
706
706
PSKIP
PSKIP
-DUP
-DUP
25
25
000
000
PS
PS
PRIO
PRIO
25
25
µ
000
000
88
100
100
DTCS
DTCS
EM
PS
PS
PRIO
PRIO
-DUP
-DUP
75
75
µ
000
000
43
439
706
706
q
!6 i e o
we r ty
!1
!8!1y !4
!2
!3
!7
q
!4
!5
!6
!7
u
u
t
!0
!6 w r e o
!8!1!2 !4
!7
i
!3
!0
i
o
!0
