Icom IC-E92D Instruction Manual

63
8
GPS/GPS-A OPERATION
New2001
7
D Position indication
q Enter “POSITION” in message/position set mode.
• GPS POSITION screen is displayed.
w Rotate [DIAL]
†
to select the received position data indica-
tion.
• MY POSITION and ELEVATION or RX POSITION and DIS-
TANCE display at the same tine when selecting SMALL on the
FONT SIZE in the set mode.
e Push [ ](5) (or [ ](4)) to return to MESSAGE/POSITION
screen.
r Push [MENU/
] to return to frequency indication.
[Indication items]
• MY POSITION : Displaying own latitude and longitude.
• RX POSITION : Displaying other station latitude and longitude.
• ELEVATION : Displaying own elevation and the time.
• DISTANCE : Displaying distance from other station.
D Saving own/received position data
q Operate q – r of “Position indication” (See left column),
and select the desired position data.
w Push and hold [S.MR](MR) for 1 sec. to save the selected
position data to GPS memory (CH00).
• The M-CH number advances automatically in case the next
M-CH is already contains information.
• 100 GPS M-CH are available.
• Push [MR] to display stored position data.
1
2
3
4
5
6
8
9
10
11
12
13
14
15
16
17
18
19
†
[DIAL] ↔ [ ](2)/[ ](8)
‡
[ ](5) ↔ [ ](6)
❮MENU screen❯ ➪ ❮MESSAGE/POSITION❯ ➪ ❮POSITION❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
MY POSITION
MY POSITION
GPS POSITION
GPS POSITION
r
34
34
°
56.78
56.78
123
123
°
45.67
45.67
E
:RX POS
:RX POS
:BACK
:BACK
N
NOTE: The ELEVATION may be overwritten by received
signal strength.
