REPEATER AND DUPLEX OPERATIONS
New2001
■ Accessing a repeater
q Set the receive frequency (repeater output frequency).
w Set the shift direction of the transmit frequency.
(–DUP or
+DUP; see p. 32 for details.)
e Push and hold [TONE](7) for 1 sec. to activate the subau-
dible tone encoder, according to repeater requirements.
• “TONE” appears.
Refer to p. 121 for tone frequency settings.
r Push and hold [PTT] to transmit.
• The displayed frequency automatically changes to the transmit
frequency (repeater input frequency).
• If “OFF” appears, check the offset frequency or shift direction.
(p. 31)
t Release [PTT] to receive.
y Push and hold [SQL] to check whether the other station’s
transmit signal can be directly received or not.
A
A
TONE
TONE
FM
FM
145300
145300
-DUP
-DUP
“–DUP”or “+DUP” appears.
7
TONE
DSQ
[SQL]
While receiving
While transmitting
A
A
TONE
TONE
FM
FM
PSKI
PSKIP
-DUP
-DUP
A
TONE
TONE
FM
FM
144700
144700
PSKI
PSKIP
-DUP
-DUP
145300
145300
