■ Resetting
The display may occasionally display
erroneous information (e.g. when first
applying power). This may be caused
externally by static electricity or by
other factors.
If this problem occurs, turn power OFF.
After waiting a few seconds, turn power
ON again. If the problem persists, per-
form either or both procedures below.
• All reset
Reset the CPU before operating the
transceiver for the first time, or if the
internal CPU malfunctions, to clear and
return all programmed contents to their
default settings.
• Partial reset
If you want to initialize the operat-
ing conditions (VFO frequency, VFO
settings, set mode contents) without
clearing the memory contents, a partial
reset function is available for the trans-
ceiver.
D All reset
q Push and hold [PWR] for 1 sec. to
turn power OFF.
w While pushing and holding [VFO],
[MR] and [BAND], then turn power
ON to reset the CPU.
• “ALL RESET” appears when resetting
the CPU (See the illustration below).
CAUTION: Resetting the CPU
returns all programmed contents to
their default settings.
D Partial reset
q Push and hold [PWR] for 1 sec. to
turn power OFF.
w While pushing and holding [VFO],
then turn power ON to partially reset
the transceiver.
[NOTE]: No message appears on the
display after the partial reset is done.
ALL RESETALL RESET
PRIOPRIO WXWX EMREMR
DTCSDTCS
FMFM
B
A
14145 000000
+DUP+DUP
PRIO WX EMR
DTCS
FM
B
A
145000
+DUP
PRIO WX EMR
DTCS
FM
B
A
438550
+DUP
ALL RESET
PRIO WX EMR
DTCS
FM
B
A
145 000
+DUP
PRIO WX EMR
DTCS
FM
B
A
145000
+DUP
PRIO WX EMR
DTCS
FM
B
A
438550
+DUP
MR
S.MW
B
VFO
MHz
A
BAND
D
PWR
13
OTHER FUNCTIONS
