Icom IC-E92D Instruction Manual

129
13
OTHER FUNCTIONS
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
■ Font size
Displayed character size during MENU mode indication in
the function display is selectable from Large and Small.
■ Display backlighting
The transceiver has display backlighting with a 5 sec. timer
for night time operation. The display backlighting can be
turned ON continuously, turned AUTO or turned OFF, if de-
sired.
■ LCD contrast
The contrast of the LCD can be selected from 16 levels.
■ Power save
The power save function reduces the current drain to con-
serve battery power.
The power save duty cycle, the ratio of receive circuit on
to receive circuit off during standby, can be set to auto-
matic1
(default), 1 : 4 (150 msec. : 600msec.), 1 : 8 (150 msec. :
1200msec.), automatic2, in addition stopping the operation of
a digital block at the DV mode, or OFF with “POWER SAVE”
in set mode.
(p. 96)
• “AUTO1” selects “1:4” duty ratio when receiving no signal for 5
sec., then “1:8” 15 sec. after that.
• “AUTO2”
suppresses the consumption of the battery by stopping
the operation of a digital block of the DV mode in addition to the op-
eration of Auto1.
❮MENU screen❯ ➪ ❮DISPLAY❯ ➪ ❮FONT SIZE❯
(Push [MENU/
]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
❮MENU screen❯ ➪ ❮DISPLAY❯ ➪ ❮BACKLIGHT❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
NOTE: The set font size is available in menu, DTMF mem-
ory and select memory write screens only.
❮MENU screen❯ ➪ ❮DISPLAY❯ ➪ ❮LCD CONT❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
❮MENU screen❯ ➪ ❮SET MODE❯ ➪ ❮POWER SAVE❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
150 msec.
15 sec.
600 msec.
1200 msec.
No signal
5 sec.
Circuit ON
Circuit OFF
†
[DIAL] ↔ [ ](2)/[ ](8)
‡
[ ](5) ↔ [ ](6)
