Icom IC-E92D - Transmission Condition Setting

57
7
DV MODE OPERATION
New2001
7
D Low-speed data communication application
setting
Confi gure the low-speed data communication application as
follows.
• Port : The same COM port number as IC-E92D’s
• Baud rate : 38.4 kbps
(fi xed value)
• Data : 8 bit
• Parity : None
• Stop : 1 bit
• Flow control : Xon/Xoff
D Low-speed data communication operation
NOTE: Confi rm that in AUTO, the computer controls when
[PTT] is activated to send data and the user doesn’t have
to operate the radio.
q Set your own, station call signs, etc. as described in “Dig-
ital voice mode operation”
(p. 38) and “Digital repeater op-
eration”
(p. 41).
w Refer to the instructions of the low-speed data communi-
cation application.
e To transmit data
• At the same time as your voice audio, push and hold [PTT] to
transmit while sending data from the PC. Release [PTT] to re-
ceive.
• Under computer control, see Transmission condition setting at
right.
D Transmission condition setting
q Enter “DV DATA TX” in DV set mode. (p. 100)
w Rotate [DIAL]
†
to select “PTT” or “AUTO.”
PTT : The input data from [DATA/SP/MIC] are transmit-
ted when pushing [PTT].
(default)
AUTO : The input data from [DATA/SP/MIC] are transmit-
ted automatically when the data are input.
e Push [ ](5) (or [ ](4)) to return to DV set mode, and push
[MENU/
] to return to frequency indication.
✔ For your information
While operating low-speed data communication via the inter-
net network from one zone to another zone, some packets
may be lost due to network error (poor data throughput per-
formance). In such a case, the IC-E92D displays an “L” in the
upper right corner on the display to indicate Packet Loss has
occurred.
†
[DIAL] ↔ [ ](2)/[ ](8)
‡
[ ](5) ↔ [ ](6)
1
2
3
4
5
6
8
9
10
11
12
13
14
15
16
17
18
19
❮MENU screen❯ ➪ ❮DV SET MODE❯ ➪ ❮DV DATA T X❯
(Push [MENU/ ]) (Rotate [DIAL]
†
, then push [ ](5)
‡
.)
L
DV
DV
B
43
430
712
712
50
50
Appears
